| Applicable panel size | 2G(370x470) ~ 10.5G(2940x3370) mm |
|---|---|
| Minimum thickness of applicable panel | 0.3mm or more |
| Cleaning speed | Recommended = 180mm/s, Maximum = 300mm/s |
| Cleaning power | Remove 99% or more of silica powder(1.6um or more) ※ According to CTS standard particle |
| Nozzle standard gap | 1.5 ~ 2.0mm |
| Power | AC208V 3P 50Hz / 50Hz |
| Panel supply | Robot / Conveyor |
| Ultrasonic non-contact dry cleaning machine | A single-face dry cleaner that cleans 0.3mm or thicker panels by using ultrasonic air without touching the panels |
|---|---|
| A-type | A-type vacuum-lifts a panel on the vacuum stage and transfer the USChead |
| B-type | B-type vacuum-lifts a panel on the vacuum stage and transfer the vacuum stage |
